of the truck, as shown in Figs. 2 and 3, these serving to prevent shifting while the subse-quent operations are going on. Each succeeding section is made sufficient-ly smaller than the one next below it to go inside of it, the model having the sections composed of tubular corner pieces, though in practice angle-iron would be preferable, because space could be better utilized. The method of attaching the ropes by which the tower is raised will be understood .4,1 from an inspection of Fig. 4, where, sup-, i( posing t'imopes A A to be pulled down-wards by the operation of the windlass, they vill, of course, raise the section B B, to which the:- -are attached at the bottom, as shown; and this section acting upon rope C U raises the next upper section; rope C C being attached at one end to the section A- A, as shown, while the other ends are attached to the bottom of the next higher section, and so on up to the top, all the sections moving to-gether. Safety catches adapted to engage with notches formed in the corner pieces pre-vent the sections from coming down in case of the breakage of a rope, or by reason of any other accident short of a complete breakdown. At each corner of the truck are attached guy ropes which reach to the top, and are so arranged that they maintain an equal tension at all times, thus steadying the tower. The upper or supplementary ladder is in two parts, one of which slides within the other, so that it can be extended to any de-sired distance within its limits, and there are hooks placed at the end that are so arranged that upon striking anything—such as the side of a building—they are thrown into position to catch upon a window-sill or other projection, and support the extreme end. The cage is guided and kept in place by a light chain, which extends from the top to the bottom, passing through the cage, which is handled from the platform, and permits per-sons to be let down in almost absolute safety. Usually the top of the tower will be above the telegraph wires, but in case it is desired to work through them there is a means of cutting through them. The mechanism by which all this is ac-complished is simple; in fact, such mechan-ism as has been used for other purposes, and is known to be practicable. So far as can be judged from tin model, the tower ought to

MACHINIST AUGUST 25, 1892    Machine Shop Observations at Fitch-burg, Mass.
PUTNAM MACHINE COMPANY.
About the year 1836 J. & S. W. Putnam began the manufacture of machine tools for the market. These brothers started in busi-ness at Fitchburg some years previous to this date, all by themselves, as it were, in a little building on Water street, which building, we believe, has been demolished. Their work was principally in the way of doing repairs. Before long they called an apprentice to their assistance—Carter Vanderford—who remained in their employ and that of the company that grew up from their humble beginning, until his death, a year or two since. In 1830, as near as can be determined, the Putnam Brothers built, for their own use, the lathe which we

illustrate on page 5 as a relic, and as showing the state of
did not begin the manufacture of machine tools for sale until about the year 1836. One of the first tools brought out, we believe, was a gear cutter, -11ich found much favor, some of those originally made being in successful use to day. The tools brought out by the Putnams found immediate favor; they were convenient in operation, neat in design, and of a finish then very popular, but which would, to-day, be considered rather too ornate. The " Putnam" tools found such ready sale that, in 1858 (the brothers had previously moved into larger shops) the present Putnam Ma-chine Company was organized. About this time the well known Putnam steam engine was brought out. This was claimed to be an infringement on existing patents, but the courts decided in favor of the Putnam Com-pany. Since then the company has done an extensive business in the manufacture of these engines, in addition to its business in
the largest foundries in New England. In addition to these are other buildings, such as brass foundry, paint shop, pattern shop, tool room, storerooms, etc., etc. Besides these shops the company hag, sin,, the consolidation with the Putnam Tool Co., an additional shop on another street, 130x45 feet, three stories high, with a large base-ment and wing. This brief and incomplete reference to these works will give some idea of the ca-pacity for turning out tools and engines with which most of our readers in this and other countries are familiar. In a recent visit to the shops we found them very busy on heavy tools, and fairly busy on steam engine work. On light tools there was not so much activity. We noticed under construction a lathe for the Brooklyn Navy Yard. This lathe is 80 feet long be-tween centers, and 74" swing. It is a " dou-ble-header," that is, it has two heads and two foot-stocks ; it has three carriages. We shall not, at this time, attempt a description of any of the characteristic features of this lathe, as we expect soon to fully illustrate it. There was also under construction an 84" swing lathe, but not so long as the government lathe.       A noticeable feature of the Putnam works is the length of time that men remain in the employment of the company. This is partly due to the fact that it is a good place to work, and partly to the fact that the com-pany never discharges a faithful workman because of the inroads of advancing years. The writer had means of knowing some-thing of the shop force of this company thirty years ago, and was surprised in his recent visit to see so many of the " old hands" still at their posts. It is a practice—this retaining of elderly men—so opposed to that of the more customary practice of send-ing men adrift after getting the work of a few of their younger years, as to deserve this brief mention. There is little danger of strikes where such a spirit, with other senti-ments sure to accompany it, prevails. It was noticed that the management is alive to the necessity of devising new meth-ods of doing work that shall cheapen the cost of product without infringing on its ellaractiir am t ft..

***************************************************************************************************************************************to

 to work through them there 14 11. ints:iiis ()I' cutting through them. The mechanism by which all this is ac-complished is simple; in fact, such mechan-ism as has been used for other purposes, and is known to be practicable. So far as can be judged from the model, the tower ought to prove very useful for the purposes for which it is designed. The inventor is Mr. Charles Albert, 35 Clifton avenue, Cincinnati, Ohio.

  ----------

AMERICAN- MACHINIST  pg-7 top and bott.

4'-:'-`3° r i F 1 „) 1.7 , LA-.A.1:-.LYR ICA -NT MA_ Ciill INT-1ST
ST 25, 1892]
world, to his family (if he has one), to him-self ? The answer is, nothing. He does not stay in a town long enough to buy himself a suit of clothes before the old fever takes its hold, and he imagines that he can do better elsewhere, so he leaves that place for another, and so on. Everywhere he will boast to our boys that he made $5 per day in New York, $6 -per day in Pittsburgh, and so on, thereby making them think that as he made such wages there, and is only getting $2 in their town, that they, too, could do better if they were to start " on the road," as he calls it. Now let's follow our young man, for it is lie that we are interested in. We will con-sider that he is a man of 20 years, that has only partly served his time, and is getting $1 per day. Going to a neighboring town be chances to get a job by representing himself to be a finished machinist, and is put to work at $2 per day, with the agreement that the wages will be raised as soon as he proves that he is worth more. I am sorry for him, but that day never came, for before the week was up lie had lost his place, simply because he got stuck on a simple job. But he got another place, and soon lost it. After awhile he got used to roving, lost all ambition to better himself, being contented to make a living some way or another, and at last we find him boasting about the high wages that he has command-ed, when $2 per day is the most he ever earned. Of course, there are good men who are compelled to wander around some times on account of slack times, etc , but when they do get a job they are pretty likely to hold it, and they will be the last ones to advise you to start " on the road." Well do I remember when the desire to " strike out " came over me. I wrote to the AMERICAN MACHINIST for advice, and was told to stay at home, which I did, and have lived to thank that kind editor for his ad-vice. As a parting word, ]et me ask every young man to work to the interest of his employer, thereby benefiting himself, for such thin us will be notieed 1)0 ►(►, g(► trtutildttg; and
1 1 .1 r 11 Ilia • ssat ta►il   #

possible from expansion. Why is it, we may ask, is there so little trouble with car axle bearings, comparatively speaking? Simply

ENGINE BEARINGS.
because they are " badly fitted " to the eye of the unlearned apprentice; they have end play and very little bearing surface, and are at best rough pieces of work, but they serve their purpose, and we all know that different classes of bearings will endure very different load intensities, according as the work through them varies in its application. The crank-pin carries a much higher unit stress than the crank-shaft, though not perhaps so much higher as it is often thought to do in the absence of any consideration as to the inertia of the piston-rod, crosshead, etc., and yet the velocity of rubbing is fairly high on a crank pin which has a big diameter, though it loses surface by its shortness. The poor, cheap engine seen by Bell Crank had at least a cap to its bearing which was de-prived of much of its power to cause a grip-ping action, and to such an extent is a better design than the more expensive Fig. 1 type. The same gripping action is characteristic of locomotive bearings, unless provision be made to prevent it. Bearing stresses are usually calculated at so much per projected area of bearing, this area being the length X diameter, but this does not mean that a bearing stress thus obtained, of say 130 pounds per square inch, is a proper figure for a crank-shaft. It does, however, tell us that a proper intensity of pressure per actual bearing is such that it should not exceed what the figure of 130 upon the whole pro-jected area. The actual intensity over the really effective part of a bearing may be 260. Given good design there is no harm in the scraping done by Bell Crank ; the trouble is that it was done upon a bad design. It was ►ecitume of the constant II ft ing of the crank In flit, toil homil 1111U111(94 (11111
cylinder to rid itself of exhaust staam at high speeds. A wheel so small that the back pressure becomes very great may exert less rail pull than a larger wheel which can allow a better effective pressure on the piston, and one of the more prominent facts of American practice to-day is the adaptation of larger and larger wheels. Americans seem deter-mined to run some trains as fast as they are run on this side, and they are going the same way to do it, only they have not tried single wheels. The illustration of the English en-gine on the P. R. R making a slow start is merely confirmatory of what one sees here with compounds. They are not always con-veniently stopped for effecting a good start, and as they have only a pair of 14-inch cylinders this is not surprising, but they can pull a heavy train when they are started, and get the 30-inch cylinder working also. Would Mr. Crane say if he found any trouble arising with the use of the brick arch in steel fire-boxes? W. H. BOOTH.

At (d) we have a volume .4 and an amount of steam of 4 X 8.25 = 33; at (b) we have a volume _4 . Therefore a pressure 33 n--. n 4— 8.25 n. This must be equ1a615tonthe pressure found before, 8.25 n — 5 n 3 "
n— 3.4 and —n = .294.
Having thus ascertained the point of cut-off in the L. P. cylinder we will now trace the correct expansion line. The volume at (b) is as follows : In H. P. cylinder (1 — .294) = .706 In receiver 4. In L. P. cylinder (.294 X 4) = 1.176
The Compound Engine. Editor American Machinist : I have read with interest Mr. Weightman's article in the number of the 28th, and would like to invite discussion about some points not quite clear to me. In the single-cylinder engine he figures the mean effective pressure quite correctly 28 96 pounds. Now this is purely theoretical, and it is all we can ever hope to get out of the amount of steam that he assumed to go through the engine. How is it possible that he can figure out a higher mean effective pressure t31.374) by using two cylinders? If this were true it would be next to a perpetual , motion, because it takes only 28.96 to comprem the steam from 8.25 to 165 (if done Iii ii prIturla ovliodorl. and wo would met buck
5.882
and the pressure is 165 : 5.882 = 28.05. At this point, as soon as the L. P. steam valve closes, the amount of steam (165) is di-vided into two parts—the one that always re-mains in the receiver and the one that goes through the engine. The value of the latter we know, but it will be interesting to figure it here again. In the L. P. cylinder we have the volume .294 x 4 1.176; 1.176 X 28.05 = 33; amount of steam going through engine. The first is the product of the volume 4.706 into the pressure 28.05, or 4.706 X 28.05 = 132; amount of steam remain-ing in receiver. At the end of the stroke   this whole amount of steam has been pushed into the receiver and occupies now only a space = 4 vols. Its pressure is there-fore 132 : 4 = 33 pounds, which demon-strates the correctness of my calculation. Of course with this point of cut-off the work of the t wo cylinders will not be the same for each. If this is the condition the actual diagrams must be laid out (allowing losses between cylinders) then the mean effective pressures mint be measured and compared, and the point of cut off in the H. P. cylin-der shifted accordingly, and new diagrams laid out. To lay out the curves for a triple-expansion engine is a little more complicated, and I will not do it here, but wait first for the criticism of this art He which is sure to come. F. F. N t(iK

----------------------------------------

pg 7 bott    weight and work it transinitte(l wore so great as to produce flexure of the shaft within the bearing, then it would be a positive benefit to make it larger in diameter, and thereby get additional bearing surface both by pre-venting flexure and increasing the surface area of the shaft. So it would seem but reasonable that a large and long bearing would stand a much better chance of having sufficient bearing surface than a short and small one would have. Increasing the diame-ter of the shaft beyond that necessary to attain the desired stiffness, would probably be of no benefit, from the fact that the increase of weight of the shaft would increase the friction enough to neutralize what would be saved by decreasing thy pressure per square inch of surface, unless the pressure were great enough to force out the lubricant. Increasing the diameter of a crank-pin will not greatly increase its tendency to heat, because if its diameter is double, the velocity of its surface is doubled, but this is almost neutralized by the fact that the pressure per square inch of surface is reduced just half. The main considerations therefore in deter-mining the diameter of a crank-pin should be, fist to give it sufficient transverse strength, and second, sufficient surface area so that the maximum pressure per square inch of surface may not exceed 14,000 pounds and which in marine engines seldom exceeds 800 pouno a true urmal P K, In speaking of surface area of -1 the normal arc --;ns I mean the pr,, in no way dependent upon the curvature of the pitch line 0 K, they are the same,for the same arc 0 H on all curves, and therefore all odontoids traced on the same side of any number of different pitch-curves by tlie “me point on the same roller are similar ',)/ -

Rotting sj)trals

fly fRSO
POWER MORTISING MACHINE.
" machinist " to think. For him not to think, is soon to become an unknown quantity, and in a very short time he will be found " help-ing " in the foundry, or a " roustabout" on the river. The experience I spoke of is only one of the many " schemes" devised by the writer, who claims to be no exception unless be that he is slower than his neighbor.
•
J" —,er, and babbitt boxes each 6" long, carried on top of a vertical slide, which is raised and lowered by means of a screw and hand-wheel shown _II, fr.,it. The cylinder is 5" square, cast on the shaft, and is provided with T slots on four sides, which admit -f changing the location of the knives to desired location. The length of the head is governed by the kind of work it is to be used for. It is compact, occupying but 3' X4' floor space. Manu-factured by the Garden City Fan Company, Chicago, Ill.
groove 'ill tilt) ()eatsa the wood I i'"xl r 1,4, 1'1+('(+i \'(+ hemp, pia it, oil iny rod, screwed up the nut and had as good a head as any one wood want for a short time.
Another piece of oak 1" thick did duty for a cylin-der-head, and was ready to " run " an hour before noon. Of course all hands were pleased when the engine moved off nicely and did its work well. But I reckon Mr. Owner must had some communication with Prof. Sweet, for his remarks proved it: " Pshaw ! we could have done that ourselves." HARRY HART.
New Wood-Working Tools.
The power mortising machine which we illustrate, has a frame cast in one piece. It is r .ed with two tables, one of which is and the other compo(md ; the work
MACHINE F.
--•11111111.•
The Theory of Gas Engines.
EXTRACTS FROM A TREATISE ENTITLED, ' NOU-VELLES RECHERCHES SUR LES CONDITIONS PRACTIQUES DE PLUS GRANDE UTILISATION DE LA CHALEUR ET EN GENERAL DE LA FORCE MOTRICE," BY M. BEAU DE ROCHAS.
When the tracing point is any ordinary When we examine what takes place in the point on the roller, the curve traced will be ai combustion chamber of a gas-fired boiler, we right angles*tO the pitch curve, but when it are struck with the enormous volume which is the pole of a spiral' it may cross at an gases raised to a high temperature attain. If angle. Fig. 22. tl4e combustion, , on the other hand, takes
Although rolled onrves and odontoids -are N constantivolume, the dilation w;" identical, they cannot readily be consideredc`.-4 6v7r-' 1-s, an the same, .for the eycif)ia  -
14, galtio41 at home, fled 414► rool dolidota smiying " I learned drawing by tho kitchoil II. 1,1.1.0 are a number of person Nvlio do sire to study let them club toget10 and start a drawing school of their own. Lot them ac-
quire a book treating upon the subject ; pro-vide themselves with a room where they can w6rk undisturbed, and begin the work at the beginning by learning to draw lines and curves ; to erect perpendiculars ; to lay off angles, and to construct squares, triangles, and polygons. Let them begin at the very beginning, and not try to " know a thing before they learn it.'! Become accustomed to handling the tools, find their " weak points," and also their own, and study to favor the one and correct the other. By the time that a - knowledge of the in-struments has been acquired, they will be able to perform most of the problems per-taining to the art of drafting ; that is, they can produce lines from, to, and in any given position. They can construct with compasses and rule about any desired figure or angle, and they will have learned how to make about any desired form of line. Let the next step be the use of ink. Study the art of " inking in " a drawing after it has been drawn in pencil. Also learn and practice the use of different sizes of lines for center work and finish lines ; and the use of red, blue and black inks in making a drawing. After thoroughly practicing the foregoing, the student will be ready to take up projec-t has been learned is but the pre-'1.,Annary study of the art of machine draw-. 1-T►on a knowledge of projection de-not other. the whole. Let the student once --41. with the wall ily understand this important part iiattl-t; and he need have no fear but perature. The ,n s-pon' represent upon paper any shape, how-answering in ea s,..1 case ,o, of tinuir nplicated it may be. work being confined its, from will assume that the class ha's fairly the -se of a slide will perfectly so world on its course. It appointed oncrern, thin thP reatest variation in the yic...d of Com- c teacher pro tem, to set fourth the lessons .stained in their text book. With chalk ,as. The arrangement, therefore,, ,of riders and a big T square, the lesson is the gas cylinders in the case in question Ca:, pawn upon a black-board for the remainder be made in the simplest manner with a co,- of the class to copy. In this manner they become accustomed to working from sight and dictation, and a com-prehensive idea of various subjects is acquired. Of course many perplexing points will come up in the course of time. It will be surprising if the teacher does not get stuck, and is not able to solve the knotty quest' which come before him. No matte,g move-things are to be expected. The t? minimum. resolve themselves into a c°117 the cylinder, whole " to cont,-)n.d with the .1arte the following questions. If ti.,ey are too asunrceelymbuestabcceessoslithi)onpfd.:iuroinf gfoaunrencotinrseest v relating to drafting
mon. slide-valve, modifying, it is al-understood, the forward and backwar,' ments of it, to meet this particular _:-- meat. _— The arrangement before descr certainly the simplest that co will, perhaps, be the only one locomotives. Then the inc7,1 - power resulting from it wit gain, and, without any tion to the cost of so; conditions of the 1 elastic force of ga the table any part of it To many , k:to •the chisel. The table unaeq-.12-' , as portant conditions  and simplicity is 3 sired angle', aPd e"-- begin the expense 01_1:6 _L1:teb 1a1 •;., sem, YZ

n Pa y, ; i l 44,-,Aet, a

HAND VALVE-RESEATING TOOL.
LETTERS FROM PRACTICAL MEN.
Hand Valve-resenting Tool, .-Zditor American Machinist: The accompanying sl-lich has proved v, .eful a. seating chest, gl fixtures 1 - ufb'
at cut the

SLOTTING MACHINE TOOL.
,n will peg A ,uare 24" long. Into the end, 0 Q SA." deep by cos V -c? P qs, 13, 'choosing special odontoids. ' 7t; ;Double contact is a curious valuable feature of gear teeth.
If
is given, WEr
cos V that will satisfy the r :t is always possible to obtai
tool-o
I WI ,,,,,, ,,•. ..... ...... _ ►inc(1 NA/►ild ho (UM of the first to adopt and sustain any measure which would be of so benefit to flu) employes as that of weekly pay1110111,H. But in this, their conclusion would bo at fault, as it would be in many other instances if they were to adopt that which would seem most natural concerning a place of this sort. The system of payment here, if such it can be called, is this : The employes are sup-posed to be paid once a month, upon which day of the month they never know, until they receive their money. Usually it arrives be-tween the first and tenth day. Twice within a year they have had to wait two or three weeks longer than the usual time, and i;,z,e they received pay for two months' work in the same week. To say that this irregularity and ofttimes delay is inconvenient, and that it sometimes brings distress upon some of the two hundred and fifty or three hundred machinists, black-smiths and foundrymen employed there, would only be stating the truth in mild terms. If the U. S. Government were hard pushed for money, or if it were some private firm which was financially embarrassed, this state of affairs might seem justifiable, but for a country with millions of dollars in the treasury is there any excuse ? G.

ADJUSTABLE REAMER.
see some of the canal   -ny of the em p- )yes, --- isthmus, an I am CENTER nipletion of the y few people on It the 'nv,-;ntion of q, );irk clone amounts house prel over There

Canal loan alone. The cra, when this great project will cause a terrible fir pference Probably M. de Dbsse the work this sprinr1c intrtre from and the realizatior 1p will, I think, ha will be hard lin :ER$
Proportioning Journal Bearings. ”for American Machinist: -- issue of March 6th, Mr. Hoffman above subject in connection for determining octontoid intersect,
angle except a right angle, the hrst 1 will have its second intersection at V-, , the secondary line of contact begins at t's ends at V, where 0 J=0 V. rd.'" ,00 The first intersection locate,,, points P' and IQ' on the primary line of cc and the second intersection locates poi and Q" on the secondary line of c All' where P K—P' 0= P'' K", L ci ' , Q' Q" = P" Q"', and b The secondary line will pass enti-rf...13, the pitch line, having apices at a b =-- 0 D; an.d b c = 0 C'. When the odontoid intersects the pitch line at a right s to the Fitch Y • ing but or 'OOLIS tion in England tact will NMI Ulilroad men are
other r q0Ong Drop xis made co Forging, 1889, and v-- TIIIS & PARKER PRESS ( on one 11P9iukii ((fee nd 1790{11MT r-,0 [Bonn Qf play, a' MIDDLETOWN, CONN.

pg-8  AMERICAN-MACHINIST-August 22 1892  page 8    AMERICAN MACHINIST

8 Communications relating to the reading columns should be addressed to the Editor. All other com-munications should be addressed : AMERICAN MACHINIST,
203 BROADWAY, NEW YORK.
PUBLISHED WEEKLY AT 203 Broadway, New York.
HORACE B. MILLER, Pres't and Bus. Manager. LYCURGUS B. MOORE, Treas. and Sec'y.
F. F. HEMENWAY, Editor and Mech. Engineer, 4. C4. A. METER'} Associates. RED, T. MILLER,
'-'peeial Announcements. rely we will neither publish anything in C- reack columns for pay or in consideration of advertising atronage. Those who wish to recommend their wares to our readers can do so as fully as they choose in,9ur advertising columns, but our editorial opinions are not for sale. We give no premiums to secure either subscribers or advertisers. al- Every correspondent, in order to insure atten-tion, should give his full name and address, not for publication, but as a guarantee of good faith. rte'- We are not engaged in procuring patent rights, or in selling machinery, nor have we any pet scheme to advance, or hobby to ride. We invite correspondence from practical ma-chini,ts, engineers, inventors, draftsmen, and all those specially interested in the occupations we represent, on sub, ects pertaining to machinery. `° Subscribers can have the mailing address of their paper changed as often as they desire. Send both old and new addresses. Those who fail to receive their papers promptly will please notify us at once. Date on wrapper denotes week with which subscription expires.
Subscription. $3.00 a year in advance, postage prepaid, in the United States, Canada, and Mexico. $4.00 a year to Other Countries, postage prepaid.
Advertising. Transient, 35c. per line, each insertion. "Business Specials," 50c. a line.
The American News Company, Publishers' Agents, New York. DEALERS SUPPLIED BY The Albany News Company, Albany, N. Y. The American News Company, New York, N. Y. The Baltimore News Company, Baltimore, Md. The Brooklyn News Company, Brooklyn, N. Y. The Buffalo News Co., Buffalo, N. Y. The Central NeWS Company, Philadelphia, Pa. The Cincinnati News Company, Cincinnati, Ohio. The Cleveland News Company, Cleveland, Ohio. The Colorado News Company, Denver, Colorado. The Detroit News Company, Detroit, Mich. The International News Company, New York, N. Y The Minnesota News Company, St. Paul, Minn. The Montreal News Company, Montreal, Canada. The National News Company, New York, N. Y. The Newark News Company, Newark, N. J. The New England News Company, Boston, Mass. The New Orleans News Company, New Orleans, La. The New York News Company, New York, N. Y. The Northern News Company, Troy, N. Y. The Omaha News Company, Omaha, Neb. The Pittsburgh News Company, Pittsburgh, Pa. The Rhode Island News Company, Providence, R. I. The San Francisco News Co., San Francisco, Cal. The South West News Company, Kansas City, Mo. tit,. Louis News Cotnimtly, St. Louis, Mo. The Toronto News co., Toronto, ('IIIU Tho ITt1Iot1 NIIWN Complosy, Now York, August 25, 1892

Machinery for Tin-plate lIl anufacture. If the New York Evening Post were less ignorant of the time and labor required to get a line of new machinery—for any manu-facturing purpose— perfected and in opera-tion on a large scale, some of its " views" upon the manufacture of tin-plates in this country might be entitled to consideration. Its latest misfit refers to an order which the American Tin-plate Co., of Elwood, Ind.—an account of the opening of whose new works was published in our issue of July 14—have just taken, through their Cin-cinnati agents, from Messrs. Norton Bros., of Chicago, for coke tin-plates equiva-lent to 5,000 boxes, 14x20 inch size, to be delivered within ninety days. Such an order is evidence that the Elwood Works are get-ting their operations down to a commercial basis. The order is further significant, be-cause of the fact that the plates are all of the lower-priced grades, such as are used in making cans, which it has been said could not be successfully made in this country. One thing is certain: the plates will be fluxed, before tinning, in palm oil, instead of ujuriatic acid, as is now and for years past has been a common practice in Wales. The sheets will, therefore, not be rust-breed-ers, ruining the goods packed in them. What especially seems to grieve the Post is the fact that Norton Bros. should presume to buy any tin-plates, in view of the pub-lished announcement as to the success of " their tinning machine by the palm oil process," as the Post graphically describes it. The Norton tinning machine now in use at their works has successfully tinned several thousand boxes of " black sheets," and cer-tainly DO mechanic will think ten or twelve months spent in perfecting it a long time in which to develop mechanism, such as the last 200 years have not—in Wales—been able to equal. The trouble with the Evening Post, in the main, seems to be, that it does not realize how many distinct mechanical operations are involved in producing tin-plates from the pig, or even from the black sheets. It affects to think that creating an industry of this magnitude is some little inconsequent operation — failure to so create it being proof that it never can be established. It l'►rgets that starting a Inn nithuactory or any 1,1nd lakes tittle, Evecially does it, take 11'ill'11 I lollut 5(1 wails he (►1
ple who must be transported daily between the city and the neighboring towns on both roads must pass over it, in addition to which it happens to be at the junction of several streets, one of them the main business thor-oughfare of Elizabeth--a city of nearly 40,-000 inhabitants. Altogether about 700 trains pass over the crossing daily, which means that during the early morning and later after-noon hours, when the local traffic is heaviest, the crossing is taxed to the utmost capacity of its numerous tracks, and limited trains are often seriously delayed there. The work of tunneling under the roads for the streets has been going on for some time, and is well advanced, while recently the work of raising the Pennsylvania's tracks has been inaugurated, those of the Jersey Central to remain at the pres-ent level. The new station buildings of the latter road are completed, those of the other road being, of course, held back until the work of raising its tracks is completed. This improvement is one, the need of which has been long seen, but it has been delayed for some years by failure to agree with the city authorities as to terms. The improvement will considerably facilitate the movement of trains, and will probably pay the roads, although its cost will, it is said, approximate $1,500,000.
      William P. Trowbridge.
William P. Trowbridge, the head of the engineering department of the School of Mines, Columbia College, New York, died recently at the age of 64. General Trow-bridge (we believe lie had that title) was one of the best known engineers in the country. He was a graduate of West Point. He served the country through the war of the rebellion. He was a member of many scien tific societies, and was one of the thirty men who met in the office of the AMERICAN MA-CHINIST to organize the American Society of Mechanical Engineers. The cause of General Trowbridge's death was heart failure.
The learned editor of the Safety Valve takes us to task for using the word mile in-stead of knot, when referring to a vessel's run. Perhaps some day—when he has nothing better to occupy his time—he will sit down :01d make plain to its, and the rest, of III w,orld, the exact, difference het %Veen a knot and tl Haul ical which, of course, is
There is little room to doubt that the employ-ment of convict miners by contractors is bad for free labor, and when the legislature re-fuses to interfere there is some reason, if not justice, in the interpos'4ion of the miners. The pe )ple and the soldiers appear to side with the strikers, so called.
A Chicago man whose name would at once be recognized if mentioned, recently spoke to the writer rather forcibly anent the World's Exposition at that city. His complaint was mainly in the direction that New Yorkers and every one else out of Chicago called the fair a Chicago institution. "Why," said the Chicagoian referred to, "this whole fair busi-ness is more a matter of New York than of Chicago influence. Chicago," said he, " is • an accident in the matter—nothing more." And we think lie is right. Literary Notes.
   POOR MANS'S MANUAL OF RAILROADS. —Tit e twenty-fifth annual edition of this standard work has been issued, and it is only neces-sary to say of it that it is fully up to the standard of former issues, and leaves nothing to be desired in the way of such a publication. No one who has any occasion to keep posted as to railroads in this coun-try, or to know something of their history and operations, especially their financial management, can get along without it. E. V. & H. W. Poor, 70 Wall street, N. Y.
We have in hand the second edition of " Rare and Useful Information for Travelers, Mechanics and Railway Men." The little book contains useful information for every one, and can be obtained from Danks & Co. Chicago, Ill. We are not informed whether or not a price is put upon the book, but can recommend it on general principles.
TREATISE ON TESTING WATER-WHEELS AND MACHINERY. By James Emerson. The author of this book, who is well known in connection with tests of water-wheels and hydraulic powers, undoubtedly knew much about such matters, but it is very evident that he has much to learn of the art of making books. If Mr. Emerson could************************************************************************************************************************************************************************************************The Montreal !slows Ce►►atiy, Montreal, cunisdii. The National News Company, New York, N. Y. The Newark News Company, Newark, N. J. The New England News Company, Boston, Mass. The New Orleans News Company, New Orleans, La. The New York News Company, New York, N. Y. The Northern News Company, Troy, N. Y. The Omaha News Company, Omaha, Neb. The Pittsburgh News Company, Pittsburgh, Pa. The Rhode Island News Company, Providence, R. I. The San Francisco News Co., San Francisco, Cal. The South West News Company, Kansas City, Mo. The St. Louis News Company, St. Louis, Mo. The Toronto News Co., Toronto, Ontario, Canada. The Union News Company, New York, N. Y. The Washington News Company, Washington, D.C. The Western News Company, Chicago, 111. The Williamsburgh News Co., Brooklyn. E. D., N.Y. The Wisconsin News Company, Milwaukee, Wis. -rise International News Company, BREAM'S BLDG'S, Chancery Lane, LONDON, E. ENG., Or Stefanstrasse 18, LEIPZIG, GERMANY, will receive subscriptions for the AMERICAN MACHINIST, at 16/6 per annum, English currency, or 17 marks per annum, German currency, postpaid. Subscriptions received in Paris. France, by E. TERQUEM, 31 Boulevard Hausmann, at 20 francs per annum, postpaid.
Subscriptions received in Australia by W.WILLIA.3ffs, 17 and 21 Fink's Buildings, Melbourne.
NEW YORK, AUGUST 25, 1892.
