The Gear Planer, or Shaper,
the third process invented. In 1874, William invented and patented the bevel gear planer for new forms of gear teeth shapes. All you need is a template of the new tooth form.
 https://antiquemachinery.com/images-gear/Gear-Planer-Coreliss-Bevel-Gear-Cutting-Machine-1876-Centenial-From-an-Origional-page-Harpers-Weekley-520dpi.jpeg
Gear Planer, or
Shaper, Gear-Planer-Coreliss-Bevel-Gear-Cutting-Machine-1876-Centenial-From-an-Origional-page-Harpers-Weekley-520dpi
Gleason spiral
bevel gear.  AM
mag 1927
https://antiquemachinery.com/images/gleason24inch_20adP1152216.jpg
Gear-Shaper-Courtesy-of-Fellows
-Gear-Shaper-Company
1905 Fellows gear shaper Springfield Vermont
If You Want to Produce high Grade Gears at Less Cost than Your Competitors, Install our Gear Shaper. You will require fewer machines, which means less capital invested, fewer operators and less space; and you will get smoother running gears. If your competitor already uses these machines, it is the only method whereby you can keep pace with him.
just how much the Gear Shaper would earn in your own shop we will tell you upon request. Send blue . . prints or, better still, ask us to have our representative call. Remember: That the Gear Shaper uses a theoretically correct generating cutter, all distortion due to hardening having been ground away. That only one is required for each pitch, which is correct for any number of teeth. That that Machine shown herewith will produce from 25 t r cent. more and better gears than any other ~gear cutter, otter.That our gear _gutting department is at your service for demonstrating the efficiency of this machine upon your own work. The Fellows Gear Shaper Co.
23 PEARL. STREET.
SPRINGFIELD, VERMONT, U.S.A.
AGENTS;Henry Kelley & Co., Manchester, Engjaad M. Koyemann. Dusseldorf. G4ermany. Ph. Bonvillain, Park L4rance. White, Child & Beney, Vienna, Austria. Walter 8 Stone & Co., Yokohama, Japan.
Above Gleason bevel gear cutter in my
collection when it was at Western Machine
Tool Co, in Holland Mi where it came out of
in1996.
<
Above Gleason bevel gear
cutter in my collection Picture
is from american machinist
cover circ 1910-1920
Gear-Shaper-Courtesy-of-Fellows-G
ear-Shaper-Company
Gear-Shaper-1906
Above Gleason is an Bevel Gear Cutting Machine was in my collection from Western Machine co Holland, Micigan, Picture is from Chest of books.com

Reference#: 1859 - GLEASON
Gear Bevel Straight & Spiral

GLEASON STRAIGHT BEVEL GEAR PLANER
                  MODEL #37  S/N 8061
SPECIFICATIONS:
Longest Cone distance                                          26"
Shortest Inside Cone Distance                                  2"
Largest Pitch Angle, Angular Gear                              90 deg.
Largest Pitch Angle, Shafts @ 90 deg.                          82 deg.53'
Smallest Pitch Angle, shafts @ 90 deg.                         7 deg. 7'
Extreme Ratio, shafts @ 90 deg.                                8 to 1
(larger ratios can be cut with special formers)
Largest Pitch Diameter (8:1 Ratio) Gear/Pinion                 48"/6"
Largest Pitch Diameter (2:1 Ratio) Gear/Pinion                 46"/23"
Largest Pitch Diameter (1:1 Ratio)                             37"
Min. number 14-1/2 deg. inv. teeth 1:1                         14
Min. number 20 deg. inv. teeth 1:1                             16
Largest Pitch                                                  1 DP
Longest Face                                                   10"
Work Spindle Diameter taper hole large end                     2.937"
Taper per foot                                                 7/8"
Depth of Taper                                                 6-3/8"
Diameter of Hole Through Spindle                               1.688"
Spindle Nose to Center Line                                    4.5"-30.5"
Diamter of Drive Pulley on machine                             16"
Speed of Drive Pulley, RPM                                     500
Width of Drive Belt                                            4"
Diam. of Tight and Loose Puleys on Countershaft                11.5"
Speed of Countershaft RPM                                      400
Horsepower of motor, if required                               7.5
Floor Space Required                                           82" x 113"
Net Weight                                                     11,000 lbs.
MACHINE IS EQUIPPED WITH THE FOLLOWING:
* 2 Mechanical Speed changes with change gears giving 12 speeds ranging
from 15 to 116 strokes per minute.
* 4 mechanical feed changes with change gears giving a range of 24 feeds
Price..............................................$$Call (Ref. #1859)
Please visit our web site to view photos of this and other machinery:
www.rpmachine.com
